SE-58U-59U
Mechanical Seals · O Ring Pusher Seal
SE-58U-59U
Product Overview
SE 58U and 59U Mechanical Seal for Chemical Centrifugal Pumps, Vacuum Pumps, Compressors and Reaction Kettles. single end, multiple springs, unbalanced, independent direction of rotation, bolt and lug transmission. The transmission is simple and reliable. The compensation components are pre-assembled for easy installation and good compensation. The load on the seal faces are balanced. The seal component is easy to adjust and the performance is reliable and stable.
Technical Specifications
- Model: SE-58U and 59U
- Design: Balanced
- Pressure: 1.2 MPa or Less
- Temperature: –40°C to 200°C
- Linear Speed: 25 m/s or less
- Size Range: ID 14 mm to 100 mm
Materials
Rotary Ring: Carbon / SiC / TC Stationary Ring: Al2O3 / SiC / TC Elastomers: NBR / EPDM / Viton / PTFE / FFKM Springs: SS304 / SS316 / HC-276 Metal Parts: SS304 / SS316 / SS316L / Hastelloy
Applications
Oil industry, chemical engineering, chemical fiber, food processing, pharmacy, paper pulp and environmental protection industry. Designed for chemical pumps, water pumps, piping pumps, screw pumps, compressors and other rotary devices.
Standards
Complies with DIN24960, ISO3069, GB6556, EN12756.
Media Compatibility
Oil, water, amorphous acid, alkali, salt, and organic solvents.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirement.
